Textile Industried Ectric Tractor Stand-up Driving
Buy Discount The Textile Industried Ectric Tractor Stand-up Driving with Free Sample made in China. AMOI Yunsheng is a The textile industried Electric Tractor manufacturer in China. We have been specialized in The textile industried Electric Tractor for many years. Our products have a good price advantage and cover most of the European and American markets. We look forward to becoming your long-term partner in China.
Send Inquiry
Product Description
With years of experience in production The Textile Industried Ectric Tractor Stand-up Driving, AMOI Yunsheng can supply a wide range of The Textile Industried Ectric Tractor Stand-up Driving. High quality The Textile Industried Ectric Tractor Stand-up Driving can meet many applications, if you need, please get our online timely service about The Textile Industried Ectric Tractor Stand-up Driving. In addition to the product list below, you can also customize your own unique The Textile Industried Ectric Tractor Stand-up Driving according to your specific needs.
The Textile industried Electric Tractor
This is a product specially desgned for the textile industried The beautiful shape and appearance design are more in line with the aesthetics of modern people . And we will offer you the best after-sale service and timely delivery.
This Electeric Tractor divided into two type the walkable driving and stand-up driving ,Rated traction weight have 13000LB、11000lb and 6600lb ,If you want to learn more about the paoduct’s features you can look at our operation video
This Electeric Tractor divided into two type the walkable driving and stand-up driving ,Rated traction weight have 13000LB、11000lb and 6600lb ,If you want to learn more about the paoduct’s features you can look at our operation video
| Feature | unit |
|
| model |
|
CCD6.0FDA |
| Rated traction weight | kg | 6000 |
| wheelbase | mm | 1188 |
| Operation type |
|
stand up driving |
| Wheels | ||
| Wheels type |
|
PU |
| Wheel quantity Driving wheel/Bearing wheel |
|
1/2/4 |
| Driving wheel size | mm | φ230*90 |
| Bearing wheel size | mm | φ130*55 |
| Dimension | ||
| Min.fork lowered height | mm | 170（customizable） |
| Min.fork highed height | mm | 340（customizable） |
| Max.lifting height | mm | 170 |
| Overall fork width | mm | 550（customizable） |
| Fork length | mm | 750（customizable） |
| Overall length（With /Without handle） | mm | 1520 |
| Overall width | mm | 808 |
| Overall height(With handle) | mm | 1500 |
| Min.Turning radius | mm | 1468 |
| Performance | ||
| Travel speed,laden/unladen | km/h | 5.9/4.1（customizable） |
| Gradeability,laden/unladen | % | 6/8 |
| Electrical configuration | ||
| Drive motor | KW | AC 2.2 |
| Lift motor | KW | DC 2.2 |
| Battery voltage / capacity | V/Ah | 24V/210Ah |
| Brake |
|
Electromagnetic/Regenerative |
| Controller |
|
MEGMEET |
| Weight | ||
| Battery weight | kg | 170 |
| Service weight with battery | kg | 880 |
